Burachem V 9655
Features
Burachem V 9655/V is a gasket sheet based on 100% pure, virgin PTFE. The product contains no added filler or reinforcement.
Advantages
- Good adaptability
- Low friction
Operating range
Pressure: Depends exclusively on the installation and operating parameters (please read our installation and maintenance instructions)
Temperature
- Continuous operation:
t = -240 °C ...+260 °C - transient peak temperature:
t = +315 °C
Recommended surface roughness:
RZ = 12.5 - 50 µm
Chemical resistance: pH = 0 ... 14
Universal chemical resistance,so resistant to most acids and alkalis. Not suitable for use in hydrogen fluoride, fluorine compounds or in molten alkali metals.
Standards and approvals
- FDA
Recommended applications
Industries
- Process industry
- Petrochemical industry
- Chemical industry
- Pharmaceutical industry
- Pulp and paper industry
- Food industry
Variants
9655/VP (Sheets)
9655/VR (Cuts)
9655/VRIG (rings with inner eyelet)
9655/VRA (frames)
9655/VS (segments)
9655/KO (PTFE with 25% coal)
Forms of supply
- Sheets:
1.500 x 1.500 mm
1,5 / 2,0 / 3,0 mm thickness
1.200 x 1.200 mm
0,5 /0,8 / 1,0 / 1,5 / 2,0 / 3,0 / 4,0 mm thickness - Rings and molded parts:
Standard dimensions as per DIN EN 1514-1 or ASME B16.21
