Plan 01

Internal cir­cu­la­tion in pump

Plan 02

Dead ended, clean medium

Plan 03

Tapered seal chamber bore

Plan 11

Cir­cu­la­tion, pressure increase

Plan 12

Cir­cu­la­tion, pressure increase + strainer

Plan 13

Cir­cu­la­tion, venting

Plan 14

Cir­cu­la­tion, venting, Plan 11+13, vertical pump

Plan 21

Cir­cu­la­tion via cooler

Plan 22

Cir­cu­la­tion via cooler, strainer

Plan 23

Forced loop via cooler

Plan 31

Cir­cu­la­tion, cyclone sep­a­ra­tor

Plan 41

Cir­cu­la­tion, cyclonce sep­a­ra­tor + cooler

Plan 32

External flush
